Operating Voltage:600V
Current Rating:120A
Switching Frequency:50kHz
Thermal Resistance:≤1°C/W
Insulation Resistance:≥10MΩ
Operating Temperature Range:-40°C to +170°C
Package Type:TO-247
Cooling Method:Air Cooled
Certifications:[“IEC 60950″,”UL 60950”]
The ABB 2MBI600VX-120-50 IGBT Modules represent the pinnacle of power electronics technology, engineered to withstand the most challenging industrial environments. These modules feature a robust design that combines high efficiency with exceptional reliability, making them indispensable for modern industrial automation systems.
With a power rating of 600V and 120A, these modules are capable of delivering substantial power with minimal losses, optimizing energy consumption and enhancing system performance. Their wide operating temperature range from -40°C to +125°C ensures seamless operation across various climates, from freezing cold to extreme heat.
Equipped with a high switching frequency of up to 20 kHz, the ABB IGBT Modules enable rapid response times and precise control, crucial for applications requiring fast and accurate adjustments. Their insulation resistance of ≥ 10 MΩ at 500 VDC ensures electrical safety and minimizes the risk of malfunctions due to internal shorts.
Featuring a peak reverse voltage of 1700V, these modules can handle high voltage spikes without degradation, safeguarding against potential damage caused by transient overvoltages. The TO-247-3 package type with thermal pad and screw terminal provides a compact yet durable housing that facilitates efficient heat dissipation, enhancing the longevity of the modules.
Designed for ease of integration into existing systems, the ABB 2MBI600VX-120-50 IGBT Modules come with detailed documentation and support, ensuring a smooth setup process. They are compatible with a wide range of control systems, offering flexibility for integration into diverse industrial automation setups.
